Threading Applications
We manufacture carbide threading tools designed for accurate, repeatable thread generation across a wide range of materials and thread forms.
Applications
Internal threading
External threading
Metric, UN, Whitworth, BSP, MJ, UNJ, NPT, BA, Sage, Trapezoidal, Buttress,
Acme, Stub Acme, PG, and others along with special threads
High‑precision CNC threading
Benefits
Sharp, accurate thread profiles
Excellent surface finish
Custom thread forms available
6mm, 8mm, 11mm, 16mm, 22mm, and 27mm edge length inserts
3 precision ground cutting edges
Internal and external, U, left and right hand options
Internal from ø6mm minimum bore diameter
Standard Thread Forms Available
55°, 60°, ISO, UN, Whitworth, BSPT, NPT, NPTF, Acme, Stub Acme, Tr, Rd, UNJ, MJ, Buttress, Sage, Pg, API, ELC, Buttress Casing, Vam
..........................................................................................................
from ø0.73mm minimum bore diameter
Single cutting edge
Reach up to 30.5mm
Standard Thread Forms Available
ISO, Tr, NPT, UN, Whitworth, Acme, Stub Acme
..........................................................................................................
from ø7mm minimum bore diameter
Single cutting edge
Reach up to 80mm
Standard Thread Forms Available
ISO, Tr, Whitworth, Acme, Stub Acme, NPT, UN
..........................................................................................................
Internal and external, left and right hand options
Internal from ø43mm minimum bore diameter
3 cutting edges
Reach up to 125mm
Standard Thread Forms Available
ISO, UN, Whitworth, Tr, Acme, Stub Acme,
..........................................................................................................
Internal and external, left and right hand options
Internal from ø38mm minimum bore diameter
Twin cutting edges
Reach up to 100mm
Standard Thread Forms Available
External ISO, Whitworth
..........................................................................................................
Left and right hand options
Twin cutting edges
Standard Thread Forms Available
Partial and full profile ISO
..........................................................................................................
Left and right hand options
Single cutting edge
Standard Thread Forms Available
Partial and full profile ISO
Premier Form Tools
Manufacturers of Precision Ground Carbide Cutting Tools
Serving engineering, aerospace, automotive, medical, and precision machining industries.
